6-2 | 303B Moisture Analyzer Manual
Table 6-1 Parts List
FIGURE DESCRIPTION PART NO.
5-1 Power Supply PC Board, 120V AC/DC 303304901S
5-1 Power Supply PC Board, 220V AC/DC 303304902S
5-1 • Fuse, 0.5 A (120V) Littlefuse 314.50 205219004
F Type
5-11 • Fuse, 0.25 A (240V) Littlefuse 314.25 205219002
F Type
5-1 CPU/Display PC Board, PPM 303202901
5-1 CPU/Display PC Board, LB/MMSCF 303203901
— • PROM IC U3 303250901
5-1 Ribbon Cable Assembly 303231901
4-1 Front Panel Overlay (PPM) 303211901
4-1 Front Panel Overlay (LB/MMSCF) 303211902
3-1 Back Panel Overlay (120 V) 303212901
3-1 Back Panel Overlay (240V) 303212902
5-1 Battery 12 V, 5 Amp-Hour 203626001
— Battery Bracket 303213003
5-1 303B Rotometer Assy, Bypass and Sample 303209901
— Flow Controller Bracket 303213001
51 Flow Controller, Sample 280807005
— Electrolytic Cell, Printed 303372908S
— Electrolytic Cell, Printed 303372909S
(Government Use Only)
5-1 Filter Assembly (F-1) 272313002
• Inline Filter Frit, 2 µm, Replacement 233303002
— Bulkhead Fitting 203332002
3-1 Cable Gland 280374006
— Cable Gland Locknut 280374005
— Feet (8-32-3/8 screw) 202161000
— Plug, Sample Adjust 202216001
— Power Cord, Auto Lighter 303256901
— Instruction Manual 303230001
