116 23-03-2009 105446 06
INPUT SPECIFICATIONS
0.01 / 0.01°C / 0.01°F (Pt500/Pt1000), see
page 118 - 119 for accuracy in °C/°F
Accuracy (3- or 4-wire) ±(0.005% of rdg. + 0.005% of F.S.)
Accuracy (2-wire) ±(0.005% of rdg. + 0.005% of F.S. + 50m)
Temperature coefficient 5 ppm/°C (0-40°C) (32-104°F)
Type of connection 4 mm safety sockets
Switch test input
Signal range
on : 0-10k / off : >100k
Internal power supply 5 V (open)
Type of connection 4 mm safety sockets
Reference input
Signal range
0 – 350
Internal power supply Measuring current 0.8 mA
Resolution
0.001 / 0.01°C / 0.01°F
Accuracy ±(0.001% of rdg. + 0.002% of F.S.), see page
120 for accuracy in °C/°F
Temperature coefficient 5 ppm/°C (0-40°C) (32-104°F)
Type of connection LEMO-connector
INPUT SPECIFICATIONS
ACCURACY IN C/F
Accuracy thermocouple type E input
(excluding sensor accuracy)
±0.10°C(±0.17°F) @ -90°C(-130°F)
±0.08°C(±0.14°F) @ -50°C(-58°F)
±0.07°C(±0.12°F) @ 0°C(32°F)
±0.07°C(±0.12°F) @ 155°C(311°F)
±0.08°C(±0.14°F) @ 320°C(608°F)
±0.11°C(±0.20°F) @ 650°C(1202°F)
±0.15°C(±0.28°F) @ 1000°C(1832°F)
Accuracy thermocouple type J input
(excluding sensor accuracy)
±0.10°C(±0.17°F) @ -90°C(-130°F)
±0.10°C(±0.17°F) @ -50°C(-58°F)
±0.08°C(±0.14°F) @ 0°C(32°F)
±0.08°C(±0.15°F) @ 155°C(311°F)
