4.11 Wiring diagram – CTC-650 B/-RS
MAINS INLET
BLUE ORANGE GREY BROWN
A B C D GND
LIVE NEUTRAL
GROUND
CN2-4 CN2-3 CN2-2
CN2-1
CN1-5 CN1-4
CN1-3
CN1-2 CN1-1
HE 1
HE 2
115V/600W
115V/600W
WELL
+
-
24 VDC FAN
105356 Rev 00 Page 4
R3
PT 100
CN6-1
CN 3
CN 1
CN 2
CN3-1
CN3-2
CN3-3
CN3-4
1
1
1
1
10
CN 1
I/O PCB
RS232
SWITCH TEST + SWITCH TEST -
10
16 16
CN6-2
CN1-6 CN1-7
CN1-8 CN4-1
CN4-2
POWER PCB
CONTROLLER PCB
WITH FUSE AND VOLTAGE SELECTOR
R 1
R 2
33R/25W
33R/25W
Optional
