Ametek SurgeX UPS-1440-Li-ISO User Manual

27
UPS + Isolation User Manual
© 2020 AMETEK Electronic Systems Protection | Technical Support: 1-800-645-9721 | surgex.com
Model #: ABCE3002-21R / Part #: UPS-3000-Li-ISO
MODEL NUMBER
PART NUMBER
ABCE3002-21R
UPS-3000-Li-ISO
Type
Standard
Power Rating (VA/Watts)
2760 / 2484
Inverter Waveform
Low Distortion Sine Wave
Transfer Time
4 ms. Typical
Frequency
50 / 60 Hz.
BTU/Hr.
446
T.H.D. Max. w/100% Resistive Load
<4% On Battery
Online Efficiency (w/o Charger)
95%
Input Voltage
208
Input Current
16.0 Amps
Output Voltage
230 and 115
Output Current (VA/Watts)
12.0 / 11.5 and 24.0 / 21.6 Amps
Input Voltage Range (w/o Using Battery)
166 to 250 Volts
Output Regulation (On Mains)
+ 10%
Output Regulation (On Battery)
+ 5%
Backup Time at Full Load (0.7 P.F)
6 Minutes
Floor Mountable
Yes (Optional)
Communications Interface
DB9, USB (SNMP Optional)
Shipping Weight (lbs./kg)
142 lbs. / 64.4 kg
Dimensions (in/mm) L x W x H
20.7 x 17.26 x 6.89 /
525.77 x 438.23 x 175.00
Output Receptacle
Eight (8) NEMA 5-20 and (1) NEMA
L6-20 Receptacles
PDU Compatible
Yes

Ametek SurgeX UPS-1440-Li-ISO Specifications

General

Brand	Ametek
Model	SurgeX UPS-1440-Li-ISO
Category	UPS
Language	English
