Front Panel Controls Environmental
Power On/Off
Temperature:
0 - +40
0
C (32 to 104
0
F) Operating
Test
-20 to 60
0
C (-40 to 140
0
F) Shipment/
Load Level LED Gauge
Storage
Battery Charge LED Gauge
Humidity: 5 to 90% Non-Condensing (Operating,
Shipment/Storage)
Voltage Manager Boost LED
Altitude: 3,000m (10,000 ft) max. Operating;
Voltage Output On LED
12,000m (40,000 ft) max. Shipment/Storage.
Voltage Manager Buck LED
On Battery LED
Safety Agency and EMC Compliance:
Replace Battery LED
All Units are Listed by UL and Marked with the UL/cUL Marking.
Overload LED
Standard UPM:
Fault Code LED Products Listed To:
System Over Temperature LED
UL IEC62040, CE Mark with CB Report
Rear Panel Information and Controls Products in compliance with:
1.8 Meter Power Cord with C20 to L6-20 Plug
FCC-Part 15, Subpart B, Sections 15.107b & 15.109b
Eight (8) NEMA 5-20R and (1) NEMA L6-20 Receptacles
Class A Digital Device*
Configuration
Manager DIP Switches
CISPR11:2009,
A1; 2010, Class A*
Communications Manager DB9 Port, USB Port
IEC61000-4-2, Electrostatic
Discharge
Circuit Breaker
IEC61000-4-3, Radiated Electromagnetic Field Immunity
AC Inlet Module
IEC61000-4-4,
Electrical Fast
Transient/Burst
Immunity
SNMP Slot (Contact Factory)
IEC61000-4-5,
Surge Immunity
IEC61000-4-6,
Immunity to
Conducted
Radio Frequency
Internal Batteries Disturbances
User Hot-Swappable (See Instruction Manual)
IEC61000-4-8, Power Frequency Magnetic Field Immunity
Type: 12 Volt, High Rate 23W
IEC61000-4-11,
Voltage Dips, Short
Interruptions,
and
Quantity: 8 Batteries
Voltage Variations
Recharge Time: 8 Hours to 80%, 24 Hours to Full Charge
*Note: Class B is Available as an Option
Please Consult Your SurgeX Sales Representative
NOISE REJECTION-ISOLATION: With unit under power and an ANSI/IEEE C62.41Cat. A pulse applied either normal or common mode
at the input, the noise output voltage will be less than 10V normal mode and less than 0.5V common mode in all four quadrants (CM-NM, NM-
NM, CM-CM, NM-COM).
SURGE VOLTAGE WITHSTAND CAPABILITY: Tested under power to ANSI/IEEE C62.41 Cat. A & B (formerly IEEE587-1980). Cat. A -
6000V @ 200 amps, 0.5 usec risetime, 100 kHZ decay, Cat. B - 6000V @ 500 amps, 0.5 usec risetime, 100 kHZ decay.
Warranty/Support: SurgeX warrants the electronics and transformers used in its uninterruptib le power managers to be free from defects
in materials and workmanship for a period of five years from the date of shipment. Batteries are warranted for a period of two years from the date
of shipment. For service or support on any SurgeX product, please contact SurgeX Technical Support at (800) 645-9721 or visit the SurgeX
website at ww.surgex.com.
Battery Life Disclaimer: SurgeX’s standard battery warranty applies only to UPS and UPM products which are continuously connected to AC
mains power, except during utility power outages. Products which are regularly and intentionally disconnected from AC mains power will
experience battery discharge/charge cycles potentially far more numerous than those for which the battery was designed. As a result, products
used in such applications will experience substantially reduced battery life. For that reason, SurgeX’s standard battery warranty does not apply
for applications in which the UPS or UPM product is regularly and intentionally disconnected from AC mains power. SurgeX UPS products used
in such applications shall receive a 90 day warranty on batteries.
