27
N. Install spring and safety cover of cross beam (See Fig. 36).
O. Install drive-in ramp, optional jack tray and optional plastic oil pans
(See Fig.
37)
.According to the below diagram screw the M16*30 bolts, then attach the drive-in
ramp.
Fig.36
59
57
58
60
7
Attach the drive-in
ramp with the bolts
Screw the M16*30 bolts to
the side hole of the cross
beam
74(Optional)
75(Optional)
Fig. 37
