26
4.3 220V Circuit diagram (See Fig. 35)
220V Circuit component
Item
Name
Code
Specification
Item
Name
Code
Specification
1
Power switch
QS
380V AC
8
Lowering
alarm button
K
duplex
2
Fuse
FU
1
25A
9
Motor
M
Single phase
3
Fuse
FU
2
3A
10
Transformer
TC
24V AC
4
AC contactor
KM
24V AC
11
Limit switch
SQ
1
、
SQ
2
10A
5
Solenoid
valve
Y
24V AC
12
Thermal
relay
FR
12A~18A
6
Push button
UP
Single
13
Alarm
H
24V AC
7
Push button
Down
Single
14
Power indictor
R
24V
Fig.35
1 phase
