Head Siderail Replacement
WARNING: Replacement of Siderail MUST be completed per the instructions below and only using Amico
approved parts. Failure to comply may result in significantly-reduced effectiveness of the safety features of the
system.
Step
No.
Procedure Illustrations
1 Locate Head Siderail that requires replacement.
Make sure that replacement Head Siderail
corresponds to the correct side of the bed.
2 Disconnect the signal cable from the main
harness. To disconnect the cable, remove the
locking nut first.
3 Locate the bolts holding the Head Siderail to
the Fowler frame. Using a 1/2" (13 mm) wrench/
socket, remove the bolts and pull the Head
Siderail away from the Fowler.
4 To install the new Head Siderail, perform the
above steps in reverse. With the new Head
Siderail plugged in, check that the buttons are
working properly.
