6
Brakes
Brake lever on left side of the handlebar activates brake on front wheel and brake lever on right side of the handlebar activates brake on rear wheel.
Make sure that all bolts on brakes are tightened according to specifications and brake pads are adjusted according to rims on wheels. (2-5 mm of space between brake
pads and braking surface on rims)
Chain
Make sure the chain is tight without slack.
Gears
The gear shifter is already set, but if needed it can be adjusted this way:
1. Set the shift lever to position 3.
The cable should now have very little tension at all or even be slightly slack.
2. Set the shift lever to position 1.
The cable should now be quite tight and the yellow arrow on the shifting mechanism behind the rear sprocket should now be aligned
between the two yellow lines on the side of the shifting mechanism. When in first gear the yellow arrow points between the two yellow
lines the gear is adjusted correctly.
