Amigo E-Line User Manual

5
3. Before the first ride
Please insure that your bicycle is ready for use and properly adjusted to fit your body
Tighten the screws:
PRODUCT DESCRIPTION
TORQUE SPEC
PRODUCT DESCRIPTION
TORQUE SPEC
Stem @ steerer tube
10-12 Nm
Brake levers
3 Nm
Stem @ handlebar
8 Nm
Brake bolts
9 Nm
Seat clamp
7 Nm
Rear wheel axle
15 Nm
Seat post @ saddle rails
10 Nm
Front wheel axle
8 Nm
Bottom bracket
40-50 Nm
Kick stand bolt
10 Nm
Crank bolts
38-41 Nm
Ferder bolts
4 Nm
Seat
Adjust the seat post to a height where your knees are slightly bend when riding.
Do NOT raise the seat post above the minimum insertion mark. It should always be hidden inside the seat tube.
Handlebar
Adjust the handlebar to a comfortable position.
Do NOT raise the stem above the minimum insertion mark. It should always be hidden inside the head tube.

Amigo E-Line Specifications

General

Brand	Amigo
Model	E-Line
Category	Scooter
Language	English
