APH 5020 APH 5030 APH 6020 APH 6530 APH 100-20
max. grade ability 36 %
Drive via centrifugal clutch and hydr. power transmission hydraulic
Control (forward/reverse) hydraulic
4. Operating speed
0 - 22 m/min
0 - 28 m/min 0 - 32 m/min 0 - 28 m/min
5. Vibration
Centrifugal power 50 kN 60 kN 65 kN 80 kN
Vibration frequency 65 Hz 69 Hz 55 Hz 40 Hz
6. Superficial power
Base unit 594 m
2
/h
925 m
2
/h 1056 m
2
/h 1090 m
2
/h
w. mount. brackets 75 / 150 mm 792 / 990 m
2
/h
1260 / 1430 m
2
/h 1344 / 1632 m
2
/h 1350 / 1600 m
2
/h
7. Special equipment
Vulkollan plate
Mounting brackets 75 mm
Mounting brackets 150 mm
Protecting cover
Operating hours meter
Electrical starter
Emergency stop switch
ACEecon-system
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
—
O
O
O
O
S
S
O
O = Option S = Serial — = Not available
8. Noise and vibration data
The following noise and vibration data according to EC Machinery Directive in the version (2006/42/EC), was determined, taking into account the
following standards and directives. In operational use, values can deviate depending on the prevailing conditions.
8.1 Noise data
3)
The noise data specified in Appendix 1, sub-clause 1.7.4.u of the EC Machinery Directive is for:
Sound pressure level at the workplace L
PA
92,0 dB 95,0 dB 93,3 dB
Measured sound power level L
WA,m
106 dB 107 dB
Guaranteed sound power level L
WA,g
108 dB 109 dB
The noise values were determined, taking into account the following directives and standards:
Directive 2000/14/EC / EN ISO 3744 / EN 500-4
8.2 Vibration data
Hand/arm vibration values according to Appendix 1, sub-clause 3.6.3.1 of the EC Machinery Directive:
Total vibration value of the acceleration a
hv
4.9 m/s
2
4.9 m/s
2
5.8 m/s
2
6.4 m/s
2
8.4 m/s
2
Uncertainty K 1.0 m/s
2
The acceleration value was determined, taking into account the following directives and standards:
EN 500-4 / DIN EN ISO 5349
3)
As the permissible rating sound level of 85 dB (A) can be exceeded by this machine, operators must wear hearing protectors.
2. Technical data
32
