Park the ma chi ne on a le vel sur fa ce, and turn off the en gi ne.
•
Loo sen the coun ter-nuts (2) of the clam ping bolts (1) and turn
the clam ping bolts back a bit.
•
Use a cra ne to lift the ma chi ne about 15–20 cm | 6–8 in.
•
Po si tion the pro tec tion plate (3) un der the ma chine and hang it
in the base plate on both sides.
•
In stall the fas te ning nuts (4) with the clam ping bolts on both si -
des, and screw them on slight ly — do not tighten.
•
Align the pro tec ti on pla te cen tral ly and lo wer the ma chi ne.
LM75020000-2 HbmG gnu thci dreV nna mmA © 9102/01
3. Ope ra ti on
61
