4.1 Before towing
Before towing, mechanically release the locking brake in the
back roller:
–
Unscrew the locking screw (1).
–
Push the screws (2) to compress the springs (3).
–
Tighten alternatively and progressively the 2 screws (2) until
they come into contract (approx. 2 turns of screw).
–
Release the bypass-screw (4) by 2-3 turns.
4.2 Towing
Danger
–
Appropriate means of attachment should always be used
when towing.
–
Maximum towing speed: 0,5 km/h
–
Maximum towing distance: 300 m
In order to tow the machine, the means of attachment should be
attached to the front or rearrings in the arms (Fig.).
30
1 2 3
4
4. Towing
