Appendix 145
1208531 | 03.07.2012
(*) Optional
(**) Not available
S53 Sensor, hydraulic oil temperature
S54 Sensor, diesel tank
S55 Sensor, engine oil pressure
S56 Sensor, coolant temperature
V11 Free-running diode, buzzer, flow divider
V12 Diode, edge cutter 1
V13 Diode, edge cutter 2
Y1 Pull-in / holding solenoid
Y2 Valve, locking brake
Y3 Drive pump, forwards
Y4 Drive pump, backwards
Y5 Valve, front vibration
Y6 Valve, rear vibration
Y7 ** Valve, large amplitude vibration
Y8
** Valve, small frequency vibration
Y9 Shut-off valve, sprinkler pump
Y11
* Valve, flow divider
Y12 * Valve, edge cutter
Y13
* Valve, edge cutter
Y14 * Valve, edge cutter water
Element Description
