5.5.3 Cleaning the air filter element
–
Remove the filter cover (1) and
– Take out the filter element (2+3).
–
Check the filter element, replace if damaged.
For slight clogging:
–
Clean the filter element (2) by tapping lightly or
–
blow it from inside to the outside with dry compressed-air.
For heavy clogging:
–
Wash the filter element (3) in a non-flammable cleaning soluti-
on and allow to dry thorougly.
–
Soak the filter element (3) with clean motor oil, squeeze out
excess oil.
–
Replace the filter element (2+3).
–
Fit the cover (1) and fasten.
5. Maintenance
38
max. 5 bar
1
2
3
GX 270_8.cdr
Attention
Never run the engine without the air filter. - Rapid
engine wear will result.
Do not allow dust to enter the carburator.
Danger
Never use petrol or cleaning solutions with a low
flash point for cleaning the filter element!
Do not smoke in the working area; avoid open fire
and sparks – fire and explosion hazard!
Hazard of eyehurts – use safety goggles!
