AMP Research PowerStep - Electrical System Installation; Wiring Routing and Controller Mounting

www.amp-research.com
8/13
IM77104 rev 07.02.15
A M P R E S E A R C H P O W E R S T E P
T M
– F O R D S u p e r D u t y
4
5
4
+
_
6
20
Loop two large tie wraps through fastener cutouts in sheet metal as shown. Position
controller as shown above and cinch down tie wraps to secure controller in place. Connect
harness to controller. Make sure that locking tabs on controller/harness connector are
fully engaged.
5
5
6
5
4
14
14
Puncture grommet and
thread trigger wire
Open passenger door
Remove step plate
11
1
12
5
13
10
5
14
