Specifications
2 Chаnnel
Class
RMS power 4Ω
RMS power 2Ω
RMS power 4Ω Bridge mode
MAX power
Low-pass filter
Hi-pass filter
Frequency response
Input sensitivity
Signal-to-noise ratio
Protection system
Fuse
Operating voltage
Terminal
Dimensions (L/W/H), mm
2.200
D
200W x 2
300W x 2
600W x 1
1200W
50Hz – 250Hz
50Hz – 250Hz
10Hz – 50kHz
0.2V – 6V
90dB
+
35A x 2
12V
Clamp
234х125х53
1 Ch Monoblock
Class
RMS power 4Ω
RMS power 2Ω
RMS power 1Ω
MAX power
Low-pass filter
Subsonic
Bass boost
Frequency response
Input sensitivity
Signal-to-noise ratio
HIGH LEVEL input
Remote Subwoofer level control
Protection system
Fuse
Operating voltage
Terminal
Dimensions (L/W/H), mm
1.500 1.600 1.800 1.1000 1.1500
D
200W x 1
350W x 1
500W x 1
900W
35Hz – 250Hz
10Hz – 50Hz
0dB – 12dB
10Hz – 250Hz
0.25V – 6V
96dB
+
+
+
25A x 2
12V
Clamp
194х125х53
* external, not included
All specifications subject to change without notice.
We respect your choice!
Congratulations on your purchase of a AMP™ Amplifier.
It has been designed, engineered and manufactured to bring you the highest level of performance
and quality, and will afford you of listening pleasure.
AMP™ — ENERGY OF SOUND!
1.2000
D
250W x 1
450W x 1
600W x 1
1200W
35Hz – 250Hz
10Hz – 50Hz
0dB – 12dB
10Hz – 250Hz
0.25V – 6V
96dB
+
+
+
35A x 2
12V
Clamp
234х125х53
D
300W x 1
550W x 1
800W x 1
1600W
35Hz – 250Hz
10Hz – 50Hz
0dB – 12dB
10Hz – 250Hz
0.25V – 6V
96dB
+
+
+
30A x 3
12V
Clamp
254х125х53
D
400W x 1
680W x 1
1000W x 1
2000W
35Hz – 250Hz
10Hz – 50Hz
0dB – 12dB
10Hz – 250Hz
0.25V – 6V
96dB
+
+
+
40A x 3
12V
Clamp
274х125х53
D
600W x 1
1000W x 1
1500W x 1
3000W
35Hz – 250Hz
10Hz – 50Hz
0dB – 12dB
10Hz – 250Hz
0.25V – 6V
96dB
+
+
+
≥180A*
12V
Clamp
314х125х53
D
830W x 1
1380W x 1
2000W x 1
4000W
35Hz – 250Hz
10Hz – 50Hz
0dB – 12dB
10Hz – 250Hz
0.25V – 6V
96dB
+
+
+
≥240A*
12V
Clamp
354х125х53
