EUROPE LoopSense Installation Commissioning & Operation
Page 19
Cabling
Connector
Purpose /Pins
CN1
Not used.
CN2
Front panel Control / LCD Interface
CN3
Network Connection (Future)
CN4
High Level Interface (Future)
CN5
Monitoring / Coms from the Power Supply.
Pins
& 0V
PSU Sense
PSU Adjust
Charger ON
Batt Load
Temp sense
Batt V Sense.
CN6
USB Diagnostics
CN7
Loop Activation Key for second loop
CN8
+/- 27VDC Out
Pins
+27VDC
0V
CN9
+/- 27VDC and earth from the Power Supply / Charger.
Pins
Earth
+27VDC
0V
CN10
Coms and +/- 27VDC and earth to internal Add-Ons.
Pins
&
27VD
C
& + 0V,
& RS 485 Bus,
Tx. Enable
CN11
Diagnostics RS232
CD, RXD, TXD, DTR, 0V, DSR, RTS, CTS, RI
