Ampeg Heritage Series User Manual

Heritage Bass Guitar Cabinets
SVT-410HLF / SVT-810E
4
SVT-410HLF Jackplate
WARNING: THIS SPEAKER IS CAPABLE OF PRODUCING
SOUND PRESSURE LEVELS (SPL) WHICH CAN CAUSE
HEARING IMPAIRMENTS OR LOSS. EAR PROTECTION
IS RECOMMENDED
IMPEDANCE:
4 OHMS
POWER: 500W RMS/1000 PEAK
INPUTS
PIN 1+ = POS(+)
PIN 1- = NEG(-)
-db
LEVEL CONTROL
4
5
6
7
8
8
9
10
11
12
16
0
1
2
3
1 2 3
1. 1/4" Input / Output Jacks
2. Speakon
®
Input / Output Jacks
3. High Frequency Horn Level Control
Speakon to 1/4" Wiring Diagram
1+
1-
1+
1-

Ampeg Heritage Series Specifications

General

Usable Low Frequency (-10dB)	40Hz
Corners	Metal
Input Connectors	2 x 1/4" jacks
Series	Heritage
Category	Enclosure
Covering	Tolex
Handle	Side Handles
