Ampeg SVT-810E - Rear Panel Connector Plate Styles; 1;4 Input; Output Jacks; Speakon Input; Output Jacks; High Frequency Horn Level Control; Attenuator

HIGH
FREQUENCY
ATTENUATOR
FULL RANGE
INPUTS
OFF
–6
0
-db
LEVEL CONTROL
4
5
6
7
8
8
9
10
11
12
16
0
1
2
3
3
2
3
31
1
Rear Panel Connector Plate Styles
1. 1/4" Input / Output Jacks: Connect the speaker-level output of an amplifier to the cabinet’s Input jack. Each of the
jacks may be used as an input or a through connection.
2. Speakon
®
Input / Output Jacks: Connect the speaker-level output of an amplifier to the cabinet’s Input jack. Each
of the jacks may be used as an input or a through connection.
3. High Frequency Horn Level Control / Attenuator: Adjusts the level to the high frequency horn.
