Ampeg SVT-810E User Manual

4
Frequency Response
(+/–3 dB)
Usable Low Frequency
(–10 dB)
Impedance Power Rating (rms)
Sensitivity
(dB SPL 1W/1m)
Maximum SPL
(dB)
LF drivers HF horn Inputs/Outputs Size (H x W x D) Weight
HSVT-810E 58 Hz – 5 kHz 40 Hz
Mono: 4 (8x10)
Stereo: 8 (4x10)
Mono: 800 W (8x10)
Stereo: 400 W 2x (4x10)
100 130 8x10"
1 x 1/4" (Mono) / 1 x Speakon
®
(Mono)
2 x 1/4" (Stereo)
48 x 26 x 16 in
1219 x 660 x 406 mm
137 lb
62.1 kg
SVT-810AV 58 Hz – 5 kHz 40 Hz
Mono: 4 (8x10)
Stereo: 8 (4x10)
Mono: 800 W (8x10)
Stereo: 400 W 2x (4x10)
100 130 8x10"
1 x 1/4" (Mono) / 1 x Speakon (Mono)
2 x 1/4" (Stereo)
48 x 26 x 16 in
1219 x 660 x 406 mm
140 lb
63.5 kg
SVT-810E 58 Hz – 5 kHz 40 Hz
Mono: 4 (8x10)
Stereo: 8 (4x10)
Mono: 800 W (8x10)
Stereo: 400 W 2x (4x10)
100 130 8x10"
1 x 1/4" (Mono) / 1 x Speakon (Mono)
2 x 1/4" (Stereo)
48 x 26 x 16 in
1219 x 660 x 406 mm
140 lb
63.5 kg
SVT-610HLF 53 Hz – 18 kHz 42 Hz 4 600 W 98 125 6x10"
P
2 x 1/4"
2 x Speakon
40 x 24 x 16 in
1016 x 610 x 406 mm
115 lb
52.2 kg
HSVT-410HLF 48 Hz – 18 kHz 28 Hz 4 500 W 98 125 4x10"
P
2 x 1/4"
2 x Speakon
24 x 30 x 19 in
610 x 762 x 483 mm
73 lb
33.1 kg
SVT-410HLF 48 Hz – 18 kHz 28 Hz 4 500 W 98 125 4x10"
P
2 x 1/4"
2 x Speakon
24 x 30 x 19 in
610 x 762 x 483 mm
74 lb
33.6 kg
SVT-410HE 60 Hz – 18 kHz 43 Hz 8 500 W 98 122 4x10"
P
2 x 1/4"
2 x Speakon
25 x 24 x 16 in
635 x 610 x 406 mm
71 lb
32.2 kg
SVT-210AV 58 Hz – 5 kHz 40 Hz 8 200 W 97.8 121 2x10" 2 x 1/4"
25 x 13 x 11 in
635 x 330 x 280 mm
26 lb
11.8 kg
SVT-212AV 71 Hz – 18 kHz 40 Hz 4 600 W 99 127 2x12"
P
2 x 1/4"
25 x 24 x 16 in
635 x 610 x 406 mm
66 lb
29.9 kg
SVT-112AV 70 Hz – 18 kHz 35 Hz 8 300 W 96 121 1x12"
P
2 x 1/4"
17 x 24 x 16 in
432 x 610 x 406 mm
45 lb
20.4 kg
SVT-15E 50 Hz – 3 kHz 33 Hz 8 200 W 98 123 1x15"
2 x 1/4"
2 x Speakon
24 x 22 x 16 in
610 x 559 x 406 mm
72 lb
32.7 kg
PN-115HLF 48 Hz – 10 kHz 28 Hz 8 575 W 98 125 1x15"
P
2 x 1/4"
2 x Speakon
23.5 x 22.8 x 17.5 in
597 x 578 x 445 mm
59 lb
26.8 kg
PN-210HLF 70 Hz – 10 kHz 40 Hz 8 550 W 97 124 2x10"
P
2 x 1/4"
2 x Speakon
18 x 22.8 x 17.3 in
456 x 578 x 439 mm
44 lb
20 kg
PN-410HLF 70 Hz – 10 kHz 38 Hz 8 850 W 100 127 4x10"
P
2 x 1/4"
2 x Speakon
26.5 x 22.8 x 17.5 in
673 x 578 x 445 mm
64 lb
29 kg
PF-115HE 50 Hz – 17 kHz 35 Hz 8 450 W 99.5 125.5 1x15"
P
2 x 1/4"
23 x 21 x 14.3 in
584 x 533 x 363 mm
44.8 lb
20.3 kg
PF-210HE 53 Hz – 17 kHz 38 Hz 8 450 W 99.6 125.6 2x10"
P
2 x 1/4"
23 x 21 x 14.3 in
584 x 533 x 363 mm
47.6 lb
21.6 kg
PF-115LF 57 Hz – 3.7 kHz 32 Hz 8 400 W 99.5 125.5 1x15" 2 x 1/4"
23.5 x 22.75 x 17.5 in
598 x 578 x 445 mm
55.8 lb
25.4 kg
PF-410HLF 55 Hz – 17 kHz 30 Hz 8 800 W 101 130 4x10"
P
2 x 1/4"
27.3 x 22.75 x 17.5 in
693 x 578 x 445 mm
73.4 lb
33.3 kg
PF-112HLF 68 Hz – 14 kHz 49 Hz 8 200 W 96 122 1x12"
P
2 x 1/4"
19.8 x 17.1 x 13.1 in
503 x 434 x 333 mm
30.8 lb
14.0 kg
Technical Specifications
All specifications subject to change

Ampeg SVT-810E Specifications

General

Amplifier class	-
Frequency range	58 - 5000 Hz
Audio output channels	- channels
Peak power per channel	800 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
Product color	Black
Connectivity technology	Wired
Package weight	74800 g

Weight and Dimensions

Depth	406.4 mm
Width	660.4 mm
Height	1219 mm
Weight	63500 g
