www.ampereelectric.co.uk
Attaching the front wheel
Loosen the pin through the middle of the wheel to allow you to place the fork onto it. Make sure the
brake disc is properly inserted into the brake calliper.
Tighten the nut and hold the lever in an upright position as shown in the picture below. Once tight
push the lever in to secure the wheel.
Assembling the pedals
• Each of the 2 pedals is marked on the inside to identify right (R) and left (L).
To connect the pedals to the e-bike, place the left pedal into the left pedal arm and the right pedal into
the right pedal arm (left and right directions are determined by sitting on the e-bike). Tighten by turning
the pedals toward the front wheel using a 15mm spanner.
