Ampler Curt - Cargo Adapter for Thule Trailer; Specifications

15/16
V1.1, 24.04.19
1
2
Specications
Sizes Small 50 cm, Medium 54 cm, Large 58 cm
Parts
Frame Aluminum Alloy 6061, Double bued
Fork Carbon 1 1/8"–1 1/2"
Crankset Alloy 170 mm
Boom Bracket: Sealed BB with a torque sensor
Cargo adapter for Thule trailer
Assembly guide 1. Remove the nut from the le side of the rear drop-
out, located next to the motor. Do not remove the
motor torque washer from the dropout – keep it
aached to the axle.
2. Aach the Ampler motor axle adapter to the frame.
Use a 19 mm wrench (available in the Ampler tool-
box) and make sure the axle adapter is securely
fastened.
3. Finally, insert the two security washers, Thule trai-
ler mount and fasten them by using a 15 mm
wrench to tighten the outside bolt.
