4/16
V1.1, 24.04.19
3. Take the 4 mm hex key and carefully tighten the
same stem bolts you loosened 2 steps back.
Turn your handlebar le and right and make sure it
spins freely. If it feels a bit too tight, loosen the
stem bolts and just slightly loosen the top cap.
Assembly
1. Unwrap the pedals. The pedals are marked with R
(right) or L (le). The R pedal goes on the chain-
wheel side and the L pedal goes on the non-chain-
wheel side.
2. Tighten the pedals with the 6 mm hex key Pedals
need to be tight so make sure you put some
Pedals need to be tight so make sure you put some
force into it. Expect resistance only at the end of the
thread, if the pedal is hard to thread in from the be-
ginning then the threads must be inspected.
Insert the pedals
4 mm
6 mm
