PUTTING THE TELEPHONE INTO OPERATION
17
Wall installation
The telephone can also be installed on a wall. You require two screws in
order to fix the telephone on a wall.
Feed the guide tabs (1) on the wall-mounting bracket (2) in the slots (3) on
the rear side of the telephone. Slide the wall bracket (2) 10 mm upwards
until it audibly snaps into place.
Drill two holes whose distance apart corresponds to the bracket to be used,
insert the screws and allow them to project 5 mm from the wall. Position
the telephone on the bracket, fit the screws in the slots and slide the tele-
phone downwards a little.
Turn the receiver hook (4) in the receiver cradle 180° so that the receiver can
be hooked in.
Warning: Ensure that there are no cables or pipes etc. in the wall where
you want to drill the holes.
