Amprobe ACD-14 FX - DC and AC Microampere Specifications; Ohms and Hz Frequency Specifications

16
Ohms
RANGE Accuracy
400.0Ω 0.8% + 6d
4.000kΩ, 40.00kΩ,
400.0kΩ
0.6% + 4d
4.000MΩ 1.0% + 4d
40.00MΩ 2.0% + 4d
Open Circuit Voltage: 0.4VDC typical
Audible Continuity Tester
Audible threshold: between 10Ω and
120Ω.
Capacitance
RANGE* Accuracy**
500.0nF, 5.000µF,
50.00µF, 500.0µF,
3000µF
3.5%*** + 6d
*Additional 50.00nF range accuracy is not
specified
**Accuracies with film capacitor or better
***Specified with battery voltage above
2.8V (approximately half full battery).
Accuracy decreases gradually to 12%
at low battery warning voltage of
approximately 2.4V
DC µA
RANGE Accuracy
Burden
Voltage
400.0µA 1.5% + 4d 2.8mV/µA
2000µA 1.2% + 3d 2.8mV/µA
AC µA
RANGE Accuracy
Burden
Voltage
50Hz -- 500Hz
400.0µA 2.0% + 5d 2.8mV/µA
2000µA 1.5% + 5d 2.8mV/µA
Hz Frequency
Function
Sensitivity
(Sine RMS)
Range
400.0mV 300mV 10Hz --
2kHz
4.000V 4V 5Hz --
40kHz
40.00V 28V 5Hz --
100kHz
400.0V 100V 5Hz --
100kHz
600V 500V 5Hz -- 5kHz
400.0µA 500µA 10Hz --
30kHz
2000µA 500µA 10Hz --
30kHz
Display counts: 5000
Best resolution: 0.001Hz
Accuracy: 0.5%+4d
Diode Tester
Open Circuit
Voltage
Test Current
(Typical)
< 1.6 VDC 0.25mA
