Amprobe ACD-23SW - Resistance, Capacitance, and Diode Specs; Continuity and Temperature Specifications

10
4.000Me ± (1.5% rdg + 5 dgts)
40.00Me ± (3.0% rdg + 5 dgts)
Open circuit volts: -0.45V dc typical, (-1.2Vdc on 400e range)
Overload protection: 600VDC or AC rms
Capacitance (ACD-23SW only) (Auto Ranging)
Ranges Accuracy
4.000μF ±(3.0% rdg + 15 dgts)
40.00μF, 400.0μF ±(3.0% rdg + 5 dgts)
4.000mF ±(5.0% rdg + 20 dgts)
Minimum input range: >100nF
Overload protection: 600VDC or AC rms
Temperature (ACD-23SW only)
Ranges Accuracy
0.0°C to 400.0°C ± (1.0% + 1°C)
-35.0°C to 0.0°C ± (2.0% + 3°C)
32.0°F to 400.0°F ± (1.0% + 2°F)
-30.0°F to 32.0°F ± (2.0% + 6°F)
Sensor type: K-type thermocouple
Overload protection: 30V Max
Diode Test (ACD-22SW only)
Test current: 0.8 mA (approximate)
Accuracy: ± (3.0% rdg + 3 dgts)
Open circuit volts: 3.0 Vdc typical
Continuity
Range: 400e
Resolution: 1e
Audible indication: Less than 25e
Response time: 500ms
Overload protection: 600VDC or AC rms
