28
INITIAL DEFAULT SETTINGS OF PPS:
COMMAND PPS-1322/1302A PPS-1326 PPS-1603/10710 PPS-2322
OUT 1 1 1 -
OUT1 - - - 1
OUT2 - - - 1
VSET 0 0/0 0 -
ISET 0.0140 0.0140/0.0140 0.0140 -
OVSET maximum maximum maximum -
VSET1 - - - 0
VSET2 - - - 0
ISET1 - - - 0.0140
ISET2 - - - 0.0140
OVSET1 - - - maximum
OVSET2 - - - maximum
ADDRESS 12 12 12 12
5.5.1 OUTPUT ON/OFF
All power supplies have their outputs off upon powering up. The command "OUT" is to enable/disable the outputs.
To enable the power supply, designate the channel (PPS-2322 only) and condition (1 = on; 0 = off). For example to
disable an output, Enter:
OUT 0
To view if an output is on or off, query the status of the power supply.
5.5.2 VOLTAGE PROGRAMMING
To program a voltage, specify an output channel (PPS-2322 only) and voltage.
<NOTE:> The default output condition of a power supply is "OFF" at startup.
All values of voltage must be in volts (i.e. no millivolts). This operation holds true for voltage settings in CV mode.
Thus, actual voltage is the programmed voltage and the programmed current is the current limit. In addition, the
specified voltage value will be rounded off to the nearest multiple of resolution.
For example, to program a channel for 16 volts. Enter:
VSET 16
To readback the programmed value, send the query:
VSET?
and address the power supply to talk.
To read back the voltage output of the channel, send the query:
VOUT?
