MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live
Rebooting the MXA-MPL
To reboot the MXA-MPL, press and hold the Reset button on the front of the device (FIG. 2) for one second.
Resetting the MXA-MPL to Factory Defaults
To reset the MXA-MPL to its factory defaults, press and hold the Factory Reset button (FIG. 2) on the front of
the device for five seconds.
MXA-MPL (FG5968-10) Specifications (Cont.)
Front Components (Cont.)
Factory Reset button: Resets the unit to factory defaults when pressed for at least 5 seconds.
Rear Components:
Video Input: DVI-I multi-format video input
HDMI Out: HDMI preview video output
Audio In: 1/8th-inch mini-jack input (for use with non-HDMI audio only)
2-Pin Connector Output: 2-pin 3.5 mm Phoenix-style connector output, 12 Volts, 3 Amps
Ethernet In: 10/100 port, RJ-45 connector for Ethernet connection to network.
Ethernet Out: 10/100 port, RJ-45 connector for Ethernet connection to touch panel.
Power Input: • IEC power cord connector
• 100-240V AC
• 47-63Hz
Operating Environment: • Temperature (Operating): 32° F to 104° F (0° C to 40° C)
• Temperature (Storage): 4° F to 140° F (-20° C to 60° C)
• Humidity (Operating): 20% to 85% RH
• Humidity (Storage): 5% to 85% RH
• Power (“Heat”) Dissipation: 232 BTU/hr
Dimensions: 1 9/16” x 8 1/4” x 7 3/16” (4 cm x 21 cm x 18.2 cm)
Weight: 2.80 lbs (1.27 kg)
Certifications: • FCC Part 15 Class A
• CE EN 55022 Class A and EN 55024
• CB Scheme IEC 60950-1
•IC
• IEC/EN-60950
•UL
•RoHS
Included Accessories: • MXA-MPL Installation Guide (93-5968-10)
• MIC AC Universal Power Cord (CA1090-131)
Other AMX Equipment: • MPA-VRK, Rack Shelf 1RU 7.3" Depth (FG5968-30)
• AC-SMB, Surface Mount Bracket Accessory (FG525)
• CC-DVI-5BNCM, DVI to 5 BNC Male Cable 6' (FG10-2170-08)
• CC-DVI-RCA3M, DVI to 3 RCA Male Cable 6' (FG10-2170-09)
• CC-DVIM-VGAF, DVI to HD-15 Female Adapter (FG10-2170-13)
• CC-DVI-SVID, DVI to S-Video Cable (FG10-2170-10)
• CC-3.5ST5-RCA2F, 5-pin 3.5mm Phoenix-style to 2 RCA Female Cable
(FG10-003-20)
