DPD setup
► Typical DPD set up is as shown below.
► The ORX power should be around -20 to -25 dBm , You can add attenuators after Splitter to get the
required level as needed.
Analog Devices Confidential Information. ©2020 Analog Devices, Inc. All rights reserved.
2
18 February 2022
TX1
ORX1
ADRV9010 DPD
PA
ATTN
SPLITTER
DPD Output
Tx DPD / Ext LOL
ADRV9010 EVAL
Power Meter
