4. Battery Capacity
The battery power is displayed in 5 segments. When the battery is fully
charged, the right LED is fully illuminated; when the battery is under voltage,
the right LED flashes and needs to be charged immediately. The battery level
is displayed from bottom to top in increments. As shown in Pic 6-4:
Pic 6-4
5. Error Code
When the electric vehicle's electronic control system fails, the meter LED
will flash to display the error code. And stop normal work, only when the fault
is eliminated can exit the fault display interface (even if the meter is turned off
without troubleshooting, the instrument will not work normally after restarting
the instrument), the error reason displayed is detailed in the attached error
code list.
G. Wire harness
The 5-segment LED display shows that the power is increased
from bottom to top. When the battery is under voltage, the first LED
on the right side flashes and needs to be charged immediately.
