ANCEL X7 - Product Menu Introduction; Accessing the Main Menu

11
VCI Box Parameters
Processor
ARM 32-bit Cortex processor
Input Voltage
DC 8-16V
Operating Temperature
-10 to 70℃ （ 14-158℉ ），relative
Humidity:<90%
Storage Temperature
-30 to 120℃ （ -22-248℉ ），relative
Humidity:<90%
Communication model
Bluetooth or USB
Protocols
J1708, J1939, ISO 9141, ISO14230,
ISO15765, ISO11898, SAE-J1850 VPW,
SAE-1850 PWM, UDS, K/L lines, High
speed CAN, Middle speed CAN, Low
speed CAN and Single wire CAN
Product menu introduction
Turn on the power switch, turn the host on, and enter the following
interface:
⑦
DB15 interface
Connect to the main testing line,
connect to the vehicle through the
diagnostic connector
