General notes
Read this manual thoroughly before beginning construction. If the steps are clear and the building components are identifi ed
and ready, then begin assembly and follow the instructions step by step.
Pay attention to the safety warnings and regulations for prevention of accidents. Lack of knowledge and understanding of
regulations can endanger the crew.
For best results and for safety, follow the sequence given.
A minimum of Six (6) installers are required for the assembly and erection of this tent.
Caution:
Relevant safety features and standard specifi cations, according to OSHA safety standards, must be maintained. Construction
laborers should be instructed about the possible dangers before construction begins. As stated above, a qualifi ed supervisor
familiar with the proper assembly technique and required safety procedures should be present during the installation.
Construction Tools
Installation and dismantling should be done the correct installation tools.
Special tools provided for installation:
Diagonal Beam Brace (2) Measuring Rod
Purlin Forks Push Pole
(3) Pull Ropes (3) R Clips
Other construction tools needed during installation and dismantling:
(2) Mid Panel Guide (Optional)
(3) Pull Ropes (25’ longer than tent width)
(3) Folding Ladders equivalent to the Tent’s Eave Height
(1) 17 mm combination wrench
(2) 24mm combination wrenches
(1) Tapered Centering tool
(2) Sledge Hammers (12 lb.)
(1) Power Stake Driver
(10) Pieces of 4” x 4” x 18” wood blocks for Shims
(1) Pair of Pliers
(2) Measuring Tapes (30M)
(2) Screw Drivers
(1) Socket Set
(1) Small Mallet
(1) Cordless Drill
(1) Stake Puller
(1) Hand Truck (dolly)
(1) Fork Lift with telescoping capabilities
(1) String Line
(1) Level
Drop cloths
Chalk/Spray paint
Pull Rope
