Inlet & Outlet-Three Zone Jacket Install
Water or Glycol must always
enter from the lower inlet port of
the jacket and exit from the top
or higher jacket port.
Steam must always enter from the
top inlet jacket and exit from the
bottom or lower jacket port.
