1-2 Description of Each Component
 Evaporation trap
A chamber to prevent the evaporation of the dispensed test liquid (distilled water).
(Refer to “1-4 Function of the Evaporation Trap”.)
 Sample cup holder
Microfuge tube holder
Used for the BM-20 / 22
Used for the BM-252 / 500 / 300 / 200 in combination with the balance weight
To hold the 5 mL sample cup.
30 mL
sample cup holder
Used for the BM-252 / 500 / 300 / 200
To hold the 30 mL sample cup.
5 mL sample cup holder
Used for the BM-252 / 500 / 300 / 200 in combination with the 30 mL sample
cup holder
To hold the 5 mL sample cup
Balance weight
Used for the BM-252 / 500 / 300 / 200 in combination with the microfuge tube
holder
To hold the 5 mL sample cup without using the 30 mL sample cup holder
 Sample cup
A measuring cup to contain the test liquid dispensed from a pipette, with a
water-absorbent sheet installed, to prevent water droplets from remaining
on the edge of the pipette tip.
 Test liquid cup
A container to keep a test liquid such as distilled water.
 Thermometer (with a clamp)
Measures the temperature of the test liquid.
 RS-232C cable and USB converter
Connects to a personal computer (PC) to transmit the test
values to the PC.
 WinCT-Pipette
Software for pipette accuracy testing to convert the test liquid mass
into a volumetric value.
