Anderson WSR 1.5 User Manual

English
17
Configure IP Address
How to configure your computer/laptop with the Network IP Address
1. Log on to the computer.
2. Click the “Start” button (it should be located at the lower-
left corner of your screen), then click “Control Panel”. Click
“View Network Status and Tasks”, and then click “Manage
Network Connections”. Right-click “Local Area Network”,
then select “Properties”. When the “Local Area Connection
Properties” window appears, select “Internet Protocol
Version 4 (TCP/IPv4)” and then click “Properties”.
3. Setting IP address manually: Type IP address is 192.168.10.x
(x is from 2 to 252), and Subnet mask is 255.255.255.0. Type
the Router’s LAN IP address (the default IP is 192.168.10.253)
into the Default gateway field.

Anderson WSR 1.5 Specifications

General

Brand	Anderson
Model	WSR 1.5
Category	Wireless Router
Language	English
