53
Preventive Maintenance
Lube Components Frequency Type Type No. of Lube
Point to be (Months) of of Points or
No. Lubricated 13612Service Lube Quantity
1. Azimuth/Elevation Jackscrew Housing X Pressure Fitting SHC32 1
2.
1
Azimuth/Elevation Jackscrew Gear I* C** Pipe Plugs SHC624 10 Oz
Housing Fill and Drain
3. Polarization Drive Gear X Brush SHC32 Minimum Surface
Coverage
4. Feed Rotation Worm Gear X Pressure Fitting SHC32 2
Pillow Blocks
5. Elevation Axis Pivot Points X Pressure Fitting SHC32 2
6. Azimuth Turntable Bearing X Pressure Fitting SHC32 2
X = Lubricate I = Inspect C = Change
* Inspection requires checking for visible signs of oil leakage, draining replacing and adding oil to ensure appropriate oil
level requirements. Excessively dirty oil will require fresh oil replacement. If oil leakage is found to be excessive, refer to
appropriate troubleshooting information and perform applicable corrective action. Periodic inspection procedures can be
less frequent after first or second scheduled inspections.
** Initial oil change requirements include flushing gear boxes with a standard cleaning agent.
Lubrication Chart
