49
PARTS LIST AND ILLUSTRATIONS SECTION 9
STANDARD MODELS
24/39 32/40 40/61 63/62 84/87
Part Numbers Description Qty
A1 C654 C654 C654 C657 C657 Adaptor Ring 1
A2 C653 C653 C655 C656 C658 Draught Diverter 1
A3 C285 C285 C285 C285 C690 Hot Outlet Nipple 1
A4 C286 C292 C293 C293 C691 Cold Inlet Dip Tube 1
A5 C641 C641 C641 C641 C641 Plug Return Connection 1
A6 C381 C381 C381 C381 C381 Drain Cock 1
A7 C103 C103 C103 C103 C103 Socket Coupler 3/4" 1
A8 C449 C449 C449 C660 C660 Cover, Combustion Chamber 1
A9 C450 C450 C451 C329 C329 Cover, Burner Access 1
A10 C701 C702 C703 C704 C705 Data Badge 1
A11 C671 C671 C672 C673 - Flue Baffle 1
A12 C333 C333 C333 C333 - Service Magnesium Anode 1
A12 - - - - C333 Service Magnesium Anode 2
A13 N/A N/A N/A C694 C694 Cleanout Pad Seal 1
A14 N/A N/A N/A C300 C300 Cleanout Pad 1
A15 N/A N/A N/A C301 C301 Cleanout Pad Cover 1
A16 C247 C247 C247 C247 - Nipple 3/4” NPT x 3/4”BSP 1
A16 - - - - C247 Nipple 3/4” NPT x 3/4”BSP 2
B1 E145 E146 E147 E148 E003 Burner Assy. comprising 1
items B2, B3, B5, B7, B12
B2 C405 C406 C406 C407 C407 Pilot Supply Pipe 1
B3 C993 C994 C994 C996 C997 Burner Supply Pipe 1
B4 C965 C965 C965 C966 C974 Multifunctional Control 1
B5 C684 C684 C684 C684 C684 Thermocouple 1
B6 C136 C136 C136 C136 C136 Pressure Test Nipple 1
B7 C679 C680 E149 E149 C683 Injector 1
B8 C382 C382 C382 C382 C382 Gas Cock 1
B9 E016 E016 E016 E016 E016 Control Knob 1
B10 C112 C112 C112 C112 C112 Knob 1
B11 E507 E507 E507 E507 C252 Pilot Burner Jet Type N18 1
B12 C685 C686 C686 C687 C688 Pilot Burner c/w Jet, Pipe 1
Electrode and Lead
B13 C514 C514 C514 C514 C514 Piezo Igniter 1
C1 C464 C465 C465 C466 C670 Top Cover Outer Jacket 1
C2 C416 C417 C417 C668 B669 Base Assy. c/w Radiation Pan 1
C3 C689 C689 C689 C689 C689 Special Screw 10
C4 C661 C662 C662 C663 C664 Combustion Chamber 1
C5 N/A N/A N/A C698 C698 Leg 3
Model
Ref.
To Next Page
