What to do if the Andrews Water Heater upper sensor reading is faulty?
If the Andrews Water Heater's upper sensor reading is faulty due to the resistance being out of range, first, check the continuity of the wire harness to the upper sensor. If the wire harness is okay, then replace the upper sensor.
What to do if flame detected before ignition in andrews ECOflo Water Heater?
If the Andrews Water Heater detects a flame before ignition, ensure the gas valve has closed and that no voltage is present at the gas valve before the ignition cycle. Also, verify the wire positions on the wire harness are correct. If the gas valve is stuck open, replace it.
What to do if flame detected after heating cycle completes in andrews ECOflo?
If the Andrews Water Heater continues to detect a flame after the heating cycle completes, verify that the gas valve has closed and that there's no voltage present at the gas valve after the cycle. Also, check to ensure the wire positions on the wire harness are correct. If the gas valve remains stuck open, it should be replaced.
What to do if andrews ECOflo flame sensed out of normal sequence?
If the Andrews Water Heater senses a flame out of the normal sequence (either before the gas valve opens or after it closes), verify that the gas valve has closed completely. Ensure there is no voltage present at the gas valve before or after the ignition cycle. Also, confirm that the wire positions on the wire harness are correct. If the gas valve is stuck open, replace it.
What to do if andrews ECOflo damper end switch failed to close (stuck open)?
If the flue damper on your Andrews Water Heater is stuck open, begin by checking if the flue damper has fully opened. If it hasn't, disconnect the damper harness at the damper plug connection and check for 24 volts between the pins on the red and white wires. If there's no voltage, inspect the wire harness or measure the output on the control board (pins 1&4). If there's still no voltage at the control board, replace it. Replace the wire harness if voltage doesn't pass to the pin terminals from the control. If there is 24 volts at the flue damper connection, replace the flue damper. If the damper is open, disconnect the harness and check continuity between the pins from the black and yellow wires on the flue damper. If there's no continuity, replace the flue damper.
How to fix low flame sense on andrews ECOflo Water Heater?
To address a low flame sense issue in your Andrews Water Heater, first, determine the flame sense current in the Service mode while the water heater is operating. If it's less than 1.0 microamps, inspect the pilot flame sense rod using emery cloth. If the issue persists, replace the pilot.
What to do if Andrews Water Heater damper end switch failed to open (stuck closed)?
If the flue damper on your Andrews Water Heater is stuck closed, start by checking if the flue damper has fully closed. If not, disconnect the damper harness at the damper plug connection and check for 24 volts between the pins on the red and white wires. If there's no voltage, check the wire harness or measure the output on the control board (pins 1&4). If there's still no voltage at the control board, replace it. If voltage doesn't pass through the wire harness to the pin terminals from the control, replace the wire harness. If there is 24 volts at the flue damper connection, replace the flue damper. If the damper is closed, disconnect the harness and check continuity between the pins from the black and yellow wires on the flue damper. If there is continuity, the end switch is stuck open...
Details the manufacturer's and user's responsibilities regarding product safety.
Provides physical dimensions and required installation clearances for models.
Outlines legal requirements and standards for installation.
Specifies requirements for the installation location and clearances.
Describes key features of the ECOflo water heater.
Describes the concentric flue system and its components.
Explains the balanced flue, gas water heater system.
Provides instructions for installing the vertical flue terminal.
Specifies gas inlet connections and requirements.
Details electrical supply requirements and connection.
Specifies air supply and ventilation requirements for installation.
Details requirements for unvented hot water systems.
Provides instructions for installing the horizontal flue terminal.
Step-by-step instructions for filling the water heater.
Provides essential safety information for users.
Guidance on adjusting air/gas mixture for optimal combustion.
Step-by-step instructions for lighting the appliance safely.
Explains how to adjust the water temperature setting.
Details the procedure for selecting and setting water temperature.
Overview of recommended servicing procedures.
Guide on resetting controls from lockout conditions.
Procedure for resetting soft lockout error codes.
Procedure for resetting hard lockout error codes.
Explains how error codes appear and are displayed.
Procedure to adjust the maximum temperature setpoint limit.
Guide for service personnel to enter service mode on the display.
Troubleshooting guide for Honeywell controls with error codes.
Troubleshooting steps when the main power light is off.
Diagnosing why the ignitor is not glowing.
Steps to diagnose why the thermostat is not calling for heat.
Troubleshooting steps when the main gas valve fails to operate.
Troubleshooting for a non-lit ignition module power LED.
Diagnosing issues with the burner flame repeatedly extinguishing.
Steps to diagnose why the fan is not energizing.
Troubleshooting when the thermostat does not satisfy heating demand.
General| Brand | andrews |
|---|---|
| Model | ECOflo Series |
| Category | Water Heater |
| Language | English |
