What to do if the andrews ECOflo EC230/600 Water Heater upper sensor reading is faulty?
If the Andrews Water Heater's upper sensor reading is faulty due to the resistance being out of range, first, check the continuity of the wire harness to the upper sensor. If the wire harness is okay, then replace the upper sensor.
What to do if flame detected before ignition in andrews ECOflo EC230/600?
If the Andrews Water Heater detects a flame before ignition, ensure the gas valve has closed and that no voltage is present at the gas valve before the ignition cycle. Also, verify the wire positions on the wire harness are correct. If the gas valve is stuck open, replace it.
What to do if flame detected after heating cycle completes in andrews ECOflo EC230/600 Water Heater?
If the Andrews Water Heater continues to detect a flame after the heating cycle completes, verify that the gas valve has closed and that there's no voltage present at the gas valve after the cycle. Also, check to ensure the wire positions on the wire harness are correct. If the gas valve remains stuck open, it should be replaced.
What to do if andrews ECOflo EC230/600 Water Heater flame sensed out of normal sequence?
If the Andrews Water Heater senses a flame out of the normal sequence (either before the gas valve opens or after it closes), verify that the gas valve has closed completely. Ensure there is no voltage present at the gas valve before or after the ignition cycle. Also, confirm that the wire positions on the wire harness are correct. If the gas valve is stuck open, replace it.
What to do if andrews ECOflo EC230/600 damper end switch failed to close (stuck open)?
If the flue damper on your Andrews Water Heater is stuck open, begin by checking if the flue damper has fully opened. If it hasn't, disconnect the damper harness at the damper plug connection and check for 24 volts between the pins on the red and white wires. If there's no voltage, inspect the wire harness or measure the output on the control board (pins 1&4). If there's still no voltage at the control board, replace it. Replace the wire harness if voltage doesn't pass to the pin terminals from the control. If there is 24 volts at the flue damper connection, replace the flue damper. If the damper is open, disconnect the harness and check continuity between the pins from the black and yellow wires on the flue damper. If there's no continuity, replace the flue damper.
How to fix low flame sense on andrews ECOflo EC230/600?
To address a low flame sense issue in your Andrews Water Heater, first, determine the flame sense current in the Service mode while the water heater is operating. If it's less than 1.0 microamps, inspect the pilot flame sense rod using emery cloth. If the issue persists, replace the pilot.
What to do if andrews ECOflo EC230/600 Water Heater damper end switch failed to open (stuck closed)?
If the flue damper on your Andrews Water Heater is stuck closed, start by checking if the flue damper has fully closed. If not, disconnect the damper harness at the damper plug connection and check for 24 volts between the pins on the red and white wires. If there's no voltage, check the wire harness or measure the output on the control board (pins 1&4). If there's still no voltage at the control board, replace it. If voltage doesn't pass through the wire harness to the pin terminals from the control, replace the wire harness. If there is 24 volts at the flue damper connection, replace the flue damper. If the damper is closed, disconnect the harness and check continuity between the pins from the black and yellow wires on the flue damper. If there is continuity, the end switch is stuck open...
Lists relevant British Standards and Codes of Practice for installation.
Outlines manufacturer and user responsibilities regarding safe operation.
Discusses the product's resistance to Legionella bacteria.
Legal requirements, standards, and personnel qualifications for installation.
Guidance on selecting location, unpacking, and safety measures like chemical corrosion.
Details ECOflo features, thermal efficiency, and technical data overview.
Planning, component lists, and installation procedures for flue systems.
Details on ignition system, heat exchanger, and water/gas connections.
Requirements for natural gas, propane gas, and electrical supply connections.
Guidance on air supply and ventilation requirements for concentric flue systems.
Water quality, treatment, and connection details for vented and unvented systems.
Filling the heater, safety guides, and gas leak procedures before operation.
How to adjust the air/gas mixture for optimal combustion.
Details venturi screw settings and CO2 range for natural gas.
Describes venturi screw settings for propane gas models.
Table showing CO2 percentages and flue gas volumes for different models.
Provides general instructions for operating the water heater.
Steps for filling the heater with water before operation.
Outlines the step-by-step sequence of appliance operation.
Detailed instructions for safely lighting and shutting off the appliance.
Guidance on adjusting temperature and the function of the Energy Cut-Off device.
Describes temperature stratification and how it's managed.
Importance of servicing, pre-service checks, and safety precautions.
A table detailing maintenance tasks, intervals, and requirements.
Information about the maintenance-free Correx powered anodes.
Steps for flushing, draining, refilling, and removing sediment/limescale.
Procedures for replacing anodes and descaling the storage vessel.
How to check the relief valve and inspect the combustion system.
Troubleshooting for power light, ignitor, ignition module, and thermostat issues.
Steps to resolve issues with the gas valve and burner flame.
Lists parts for combustion, ignition, and LPG assemblies.
Lists components for the ECOflo concentric flue system.
Lists the parts included in the ECOflo Unvented System Kit.
General| Brand | andrews |
|---|---|
| Model | ECOflo EC230/600 |
| Category | Water Heater |
| Language | English |
