PARTS LIST AND ILLUSTRATIONS SECTION 9
HI-FLO MODELS
Model 32/143 65/173 81/264
Ref. Part Numbers Description Qty
A1 E023 C500 C501 Draught Divider 1
A2 C333 C333 C333 Service Magnesium Anode 2
A3 C334 C334 - Flue Connector, 150mm, BS 835 1
A3 - - C432 Flue Connector, 200mm, BS 835 1
A4 C381 C381 C381 Drain Cock, BS 2879, 3/4" 1
A5 C103 C103 C103 Socket Coupler, 3/4" 1
A6 E021 C475 C476 Data Badge 1
A7 C533 C536 C540 Flue Baffle 8
A8 C235 C235 C235 Andrews Label 1
A9 N/A C479 C479 Hot Outlet Connection, 1 1/2" BSP 1
A10 N/A E056 E055 Hydrojet Cold Inlet Connection 1
(top) 1 1/2" BSP
A11 C486 C486 C486 Top Cover 1
A12 C488 C488 C488 Insulation Pad 1
A13 E391 C489 C489 Flue Box Top Cover 1
A14 C694 C694 C694 Cleanout Pad Seal 1
A15 C300 C300 C300 Cleanout Pad 1
A16 C301 C301 C301 Cleanout Pad Cover 1
A17 C247 C247 C247 Drain Tapping Connector, 3/4 BSP 1
A19 C534 C534 C534 Nipple, 1 1/2 " BSP 4
A20 E050 E050 E050 Hydrojet Cold Inlet Connection 1
(side) 1 1/2" BSP
B1 E031 C537 C541 Burner Assy. comprising items 1
B2-B6andB8-B9
B2 C503 C503 C503 Burner Bar 5
B3 C505 C505 C505 Burner Manifold 1
B4 E017 / E552 - - Injector 2.69mm (P.P.) / 2.40mm (A.I.) 5
B4 - C538 / E551 - Injector 2.87mm (P.P.) / 2.58mm (A.I.) 5
B4 - - C542 / E553 Injector 3.66mm (P.P.) / 3.25mm (A.I.) 5
B5 C507 C507 C507 Pilot Assy. c/w injector and electrode 1
B6 C508 C508 C508 Pilot Supply Pipe 1
B7 C252 C252 C252 Pilot Injector 1
B8 C552 C552 C552 Thermopile 1
B9 C511 C511 C511 Multifunctional Valve 1
B10 C512 - - Control Thermostat/Overheat ECO 1
B10 - C539 C539 Control Thermostat with remote 1
phial and ECO
B12 C513 C559 C559 Lead Assy. 1
Thermostat to Gas Valve 1
B13 C136 C136 C136 Pressure Test Nipple 1
B14 C514 C514 C514 Piezo Igniter 1
B16 C498 C498 C498 Gas Cock 3/4" BSP FxF 1
B17 E418 E418 E418 Pilot Shield 1
C1 C480 C480 C480 Flue Damper Assy. 6” 1
C2 Control Box Assy. complete 1
C8 Gas Control Valve 1
C9 C970 C969 C969 Damper Harness 1
C10 Pilot Assembly 1
P.P. = Permanent Pilot
A.I. = Auto Ignition
