Ref. Part No. Description Qty
1 E205 90˚ Elbow with Clamp
2 E202 1 mtr Flue with Clamp
3 E236 Horizontal Flue Terminal
4 E209 Wall Clamp (Not Shown)
5 E237 Large Stepped Adaptor Connection Clamp
6 E238 200mm (8in) to 150mm (6in) Reducer
7 E203 1 mtr Cutable Flue with Clamp
8 E204 0.5 mtr Flue with Clamp
9 E239 Vertical Flue Terminal
10 E210 Condensate Trap Tee
11 E207 Flat Roof Plate
12 E208 Angled Roof Plate
13 E105 Horizontal Flue Outlet Terminal Guard
14 E206 45˚ Elbow with Clamp
PARTS LIST AND ILLUSTRATIONS SECTION 8
35
200mm (8in)
Flue Kit
Ref. Part No. Description Qty
1 E215 90˚ Elbow with Clamp
2 E212 1 mtr Flue with Clamp
3 E240 Horizontal Flue Terminal
4 E219 Wall Clamp (Not Shown)
5 E237 Large Stepped Adaptor Connection Clamp
6 E213 1 mtr Cutable Flue with Clamp
7 E214 0.5 mtr Flue with Clamp
8 E241 Vertical Flue Terminal
9 E220 Condensate Trap Tee
10 E217 Flat Roof Plate
11 E218 Angled Roof Plate
12 E630 Horizontal Flue Outlet Terminal Guard Extended
13 E216 45˚ Elbow with Clamp
150mm (6in)
Flue Kit
Note: Extra lengths of flue tubing can be supplied to suit each installation requirement.
Also extra 90˚ and 45˚ elbows can be supplied.
Note: Extra lengths of flue tubing can be supplied to suit each installation requirement.
Also extra 90˚ and 45˚ elbows can be supplied.
