INSTALLATION SECTION 3
21
WATER
CONNECTIONS
VENTED SYSTEMS
Fig 10.
Typical Installation
Vented System
Open Vent
Overflow
Hot Water Service
Optional
Hot Water Service
Secondary Return
Check Valve
Cold Water
Inlet Valve
Cold Water
Cistern
Stop Valve
Cold Water Feed
