4. Carefully cut and remove the section of liner in the spillway
opening. Fig. 4
Fig. 4
5. Apply a continuous 1/4" bead of sealer around the flange of
tank. Make sure there are no spaces or voids in the bead
between the holes and the edge of the cut-out on the flange
of the tank. Fig. 5
Fig. 5
6. Align the liner on the flange of tank, make sure the liner sit flat
on the flange of tank without wrinkling or pulling. Fig. 6
Fig. 6
7. Insert 2 temporary nails into the flange top corner hole of
tank, then holding the nails in place with hand, push the nail
through the liner Fig. 7
Fig. 7
Apply silicone on this surface
