Specications
Specifications and design are subject to change without
notice.
Power supply: DC 15V 3A
Power consumption: < 20W
Standby power consumption: < 0.5W
Display technology: 0.2 in 854 × 480p DLP
Light source: RGB LED
Projection image size: 20-100 in
Resolution: 854 × 480p
Brightness: 200 ANSI Lumens
Contrast ratio: 400:1
Throw ratio: 1.3
Throw distance: 0.58 m to 3.08 m
CPU: Quad core A7
OS: Android 7.1
RAM: 1GB DDR
ROM: 8GB eMMC
Speaker drivers: 6W
Wi-Fi: IEEE802.11a/b/g/n Dual Frequency 2.4G / 5G
Bluetooth version: 4.2
USB le system: FAT32
Built-in battery type: Li-Polymer
Capacity: 9,750 mAh 3.85V
Movie playtime: approximately 4 hours in battery mode
Music playtime: approximately 30 hours in Bluetooth speaker mode
Remote control batteries: CR 2032 × 2
Recommended ambient temperature: 41°F to 95°F / 5°C to 35°C
Relative humidity: 15% ~ 85% (non-condensing)
Storage temperature and humidity: < 149°F / 65°C, < 90% humidity
Dimensions (H × L × W): 131 × 65 × 65 mm / 5.2 × 2.6 × 2.6 in
Weight: 579 g / 16.6 oz
Troubleshooting
①
Could not turn on projector with the remote control?
• Hold for 2 seconds on the projector to turn it on.
• When powered off, you cannot use the remote control to turn it on.
②
The remote control doesn’t work?
• Make sure the battery is already installed in the remote control.
• Replace the batteries.
③
Blurred image?
• Rotate the focus adjusting knob.
④
Reversed projection image?
• Press to access the home menu, select [Settings] > [Projector
Mode] and switch to the correct state.
⑤
Cannot connect to a Wi-Fi network?
• Refresh the list of available networks and retry.
• Reboot the wireless router or the projector and retry.
⑥
How do I update the rmware?
• When a new version is detected you will be asked to reboot and
update.
