anko MITYFLEX 907 Series - Tubing Installation Procedures; Procedure A for Tubing Installation

7

TUBINGINSTALLATION
Inspectalltubingregularlyandreplaceifanysignofdeteriorationoccurs.Alwayswearsafety
glassesandprotectiveclothingwhenworkingwithchemicals.Seechartbelowforproper
tubinginstallationprocedureforyourunit.
*90_‐002through90_‐014 ProcedureA(below)
90_‐023through90_‐049 ProcedureAorB(page6or8)
90_‐058through90_‐282 ProcedureAorC(page6or9)
*WARNING:MODEL907‐002,907‐007,907‐014,908‐002,908‐007and908‐014GEARTRAINS
CANBEDAMAGEDIFDRIVESHAFTISROTATEDBYHANDFORTUBEINSERTION.
PROCEDUREA
 (Ifunitisnewstartwithstep#6.)

1. Disconnectpowertothepump.

2. Disconnectthesuctionanddischarge
tubingfromthepumptubing.

3. Removefourscrewsandpumpcover
frompumphead.

4. Pulloutoldpumptubinganddiscard.

5. Cleanrollerrace,removingand
particlesthatcoulddamagetubing.

6. Connectpowerandrunatslowest
speeduntilrollerbracketassemblyis
inpositionasshowninfigure1.

7. Pushnewtubingintoinletport,
anchoringtubingingrippers.Ifusing
a9”pieceoftube,11/2”shouldbe
extendedoutsideofinletport.(figure
2)

8. Continuetorunatslowestspeed
carefullyfeedingtubeintoraceasthe
rollersturn.(figure3)
(Keepfingersawayfromrollers).

9. Inserttubingintooutletport(figure
4)andreplacecover.



