anko MITYFLEX 907 Series - Procedure B for Tubing Installation

8


PROCEDUREB

Followsteps1‐5inprocedureA,then
continuewiththefollowing.

6. Usingextrabracket(figure1),rotate
rollerbracketassemblyuntilitisin
positionasinfigure2.(Besurepower
isdisconnected).

7. Pushnewtubingintoinletport,
anchoringthetubingingrippers(see
figure3).Ifusing9”pieceoftube,1
1/2”shouldbeextendedoutsideof
inletport.

8. Continuetorotatetherollerbracket
assemblyusingtheextrabracket,
whilepushingthetubingintothe
rollerrace.(figure4)

9. Insertthetubingintotheouterport
(figure5)andreplacethecoverand
screws.













