Typical Settings and BER Result
Recommended settings for error free condition at 26.5625 Gbaud and
28 Gbaud and loopback connection from G0375A to G0376A decoder input
are listed below.
MU195020A+G0375A
Tx
configuration
MU195020A+
MU195050A
+G0375A
Tx
configuration
G0375A
output
amplitude
400 mV (Single-end)
800 mV(Differential)
Pattern
PRBS31Q
Skew adjustment
100 mUI or less
Emphasis Pre
-cursor1
0.0
dB at 26.5625 G/
0.8 dB
at 28 G
1.0 dB
at 26.5625 G/
1.8 dB at 28 G
Emphasis Post cursor1
0.0
dB at 26.5625 G/
0.2 dB
at 28 G
0.8 dB
at 26.5625 G/
1.0 dB at 28 G
G0376A
DFF On/Off DFF On
G0376A
Input Condition Differential
Error Result
Error Free at 26.5625 G and 28 G
