Anritsu MP1900A Series - Page 21

21
Specifications Rx
MU195040A 21G/32G bit/s SI ED Data Input
Item Specification Remarks
Number of Inputs 2 (Data, xData)
K Connector (female)
Data Input Amplitude 0.3 to 1.0 Vp-p ( 28.1 Gbaud)
0.4 to 1.0 Vp-p (> 28.1 Gbaud)
Single-ended
Data Input Sensitivity 120 mVp-p, 40 mVp-p/Eye
(typ., 21Gbaud)
150 mVp-p, 50 mVp-p/Eye
(typ., 28.1Gbaud)
Eye amplitude, PRBS15, Single-ended,
CTLE Off
24 mV/Eye (typ., 21Gbaud)
26 mV/Eye (typ., 28.1Gbaud)
Eye height, PRBS15, Single-ended,
CTLE Off
Phase margin Middle eye
8 ps (typ. 25 Gbaud)
5 ps (typ. 28 Gbaud)
Upper and Lower
5 ps (typ. 25 Gbaud)
3 ps (typ. 28 Gbaud)
0.5 Vp-p input, Emphasis
control(1Pre<=3 dB, 1Post <=1 dB) ,
PRBS15, Single-ended,
CTLE Off
Middle eye
20 ps (typ. 25 Gbaud)
15 ps (typ. 28 Gbaud)
Upper and Lower
20 ps (typ. 25 Gbaud)
15 ps (typ. 28 Gbaud)
Eye width
0.5 Vp-p input, Emphasis
control(1Pre<=3 dB, 1Post <=1 dB) ,
PRBS15, Single-ended,
CTLE Off
