Outline of G0375A/G0376A 32 Gbaud PAM4 BER Solution
32 Gbaud Power PAM4 Converter
G0375A
32 Gbaud PAM4 Decoder with CTLE
G0376A
DUT
• 3.9 Vp-p (differential) PAM4
output
• 10Tap Emphasis
• Clean Eye/Low Jitter
• Tr/Tf 14 ps (typ.)
(PAM4 output)
• CTLE 14 GHz, 12 dB
• Clock recovery
(by MU195040A ED)
• High input sensitivity of
40 mV(EH)
• True PAM4 BER
measurement
Supports PAM4 BER Measurements of PRBS31Q Pattern
Loss CH
MP1900A
• Small remote head for
close-in approach to
DUT
• Multi-channel
• Excellent expandability
and PAM4/NRZ support
